Cutting Plotter

Cutting Plotter FUCTIONS AND FEATURES: 1 Adopting 32-bit RISC processor to make the cutting speed much faster. 2 Adopting precision CNC Servo-motor to make the position more accurately. 3 2MB capacity realizes rapid data copying and improves working efficiency. 4 Max pressure of cutting tool is 350gms 5 Media can be feeded both form forward and backward, convenient and flexible to operate when cutting the large advertising 6 Cutting speed can reach to 33ips 7 Equipped with USB port, Parallel port and professional software. Support PC and Apple computer. Max Cutting Width 1195mm(47) Repeatable Precision ≤0.1mm Media Size 90 1372mm Interface Parallel and USB(Rev1.1) Cutting Size 0 1207mm Buffer Capacity 2MB Kinds of Knife CAMM-1 series knifes Instruction System CAM-GLIII Cutting speed 10 850mm/s Power 0.8/100 240v±10%,50/60HZ Pressureof Cutting Tool 20 350mm/s Dimensions 1602*264*398 Mechanical Resolution 0.0125 mm/step Weight 59kg(with bracket) Software Resolution 0.025mm/step
